On Wire Splicing - eVideo

On Wire Splicing - eVideo


$17.95
SKU 2005-DISC-EVgray stars
Which product is best for you?
Qty

Product Features

  • Author: Pratt & Whitney
  • Time: 21 minutes
  • Video: https://www.youtube.com/watch?v=S2Yc4pPAfTE
  • Look Inside: View
  • File Type: eVideo (MP4)

A detailed demonstration on wire splicing and temporary wire harness repairs based on the standards and procedures recommended by Pratt & Whitney.

This video first details and identifies the components, tools, and materials used to make field wire harness splices and then demonstrates each step of the technique for splicing 20 gauge wire including:
  • Damage Inspection
  • Repair Limits
  • Stripping Wire
  • Stripping Back Shielding
  • Splice Spacing.
  • Crimping Splices
  • Installing Inner and Outer Ferrules
  • Heat Shrinking
  • Use of Lacing Tape
  • Installation of Chafe Guard
  • Performing a Continuity Test and Insulation Resistance Test
