Using Zenith 601 and 701 aircraft for demonstration, this video was filmed at a hands-on workshop provided by the technicians of Jabiru-USA to train aircraft builders to properly design and install their firewall forward components.
The following systems are covered
Engine crate unpacking and contents:
Handling/removing the engine from the crate; explanation of the break in procedure accomplished by the factory prior to shipment.
Engine Mounting techniques:
Understand special considerations for mounting the engine on the airframe: engine mount to firewall alignment, engine onto the mount itself. Rubber engine mount hardware: male-female part direction is important.
Prop flange removal/installation:
The prop flange length you need may require demonstration of removing/re-installation of the factory installed flange.
Installation of the oil cooler and the requisite connections are essential for proper operation. The oil cooler needs to occupy a specific location in the cowl.
The Jabiru supplied muffler provides the necessary heat muffs for both cabin heat and carb heat.
The key to proper cooling is the installation and customization of the fiberglass air ducts on each bank of cylinders. An in depth discussion of these issues is included.
A detailed discussion of tuning the mixture of the Bing altitude compensating carb for prop load is discussed at length. A Jabiru economizer feature is described along with the needle jets involved for this.
