Zenith CH750 Jabiru 3300  Engine Installation - DVD

Zenith CH750 Jabiru 3300 Engine Installation - DVD


$29.00 $39.00 You Save $10.00
SKU 4067-CLR-DVDgray stars
Which product format is best for you?
Qty

Product Features

  • Publisher: Homebuilt Help
  • Time: 105 min.

For CH750 builders that are considering the Jabiru 3300 aircraft engine. This video was filmed on location at Can-zac Aviation, Ontario, Canada, under the direction of Mark Townsend, the Canadian Zenith distributor. The purpose of this presentation is to demonstrate how to install the 3300 engine on a Zenith Ch750 using the firewall forward components supplied by Jabiru USA. The Jabiru 3300 provides an exciting alternative to other engine possibilities in this aircraft. With this video DVD, you can watch and learn how to install and hookup the components needed for a reliable installation.

  • Engine crate unpacking and contents: Handling/removing the engine from the crate; explanation of components included in the firewall forward kit.
  • Engine Mounting techniques: Observe and understand special considerations for mounting the engine on the 750 airframe: engine mount to firewall alignment, engine onto the mount itself. Rubber engine mount hardware: male-female part direction is important.
  • Prop flange removal/installation: The prop flange length needed on the CH 750 requires removing/replacing the factory installed prop flange.
  • Oil Filter/Cooler: Installation of the oil cooler and the requisite connections are essential for proper operation. The oil cooler needs to occupy a specific location in the cowl. Plumbing is demonstrated using the popular aero hose and connections.
  • Muffler: The Jabiru supplied muffler provides the necessary heat muffs for both cabin heat and carburetor heat. Location on the firewall for mounting airbox components is shown.
  • Cowl: The cowl requires some trimming for the variations in aircraft configurations. A cowl fitting is demonstrated.
  • Air Ducts: The key to proper cooling is the installation and customization of the fiberglass air ducts on each bank of cylinders.
